Xerox Phaser 6180MFP Service Manual

Phaser 6180MFP Multifunction Printer Service Manual 3-27
Error Messages and Codes
5 1.Perform the Registration Sensor
test (page 4-43): Service Mode >
Printer Diag > Engine Diag >
Sensor Test > Regi Sensor.
2.Does the number on the Control
Panel increase by 1 when the
Actuator of the Registration Sensor
is activated?
Go to step 6. Go to step 10.
6 1.Perform the Tray 3 Feed Motor test
(page 4-59): Service Mode >
Printer Diag > Engine Diag > Motor
Test > Tray 3 Feed Motor.
2.Does the Tray 3 Feed Motor operate
properly?
Go to step 7. Go to step 18.
7 1.Perform the Tray 3 Feed Clutch test
(page 4-59): Service Mode >
Printer Diag > Engine Diag > Motor
Test > Tray 3 Feed Clutch.
2.Does the Tray 3 Feed Clutch operate
properly?
Go to step 8. Go to step 14.
8 1.Perform the Tray 3 Turn Clutch test
(page 4-59): Service Mode >
Printer Diag > Engine Diag > Motor
Test > Tray 3 Turn Clutch.
2.Does the Tray 3 Turn Clutch operate
properly?
Go to step 9. Go to step 11.
9 1.Check the Retard Rollers and Feed
Roller for operation.
2.Are the rollers correctly installed?
Go to step 10. Are the rollers
contaminated?
Replace the
defective
Rollers.
10 1.Replace the 550-Sheet Feeder
(page 8-116).
2.Does the error still occur when
printing?
Replace the
MCU Board
(page 8-88).
Complete.
11 1. Check the wiring harness
connectors P/J27, P/J273, and P/
J419 between the Optional Feeder
Board and the MCU Board.
2.Are the connectors securely
connected?
Go to step 12. Reconnect the
connectors.
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No
