Xerox Phaser 6180MFP Service Manual

Phaser 6180MFP Multifunction Printer Service Manual 3-29
Error Messages and Codes
19 Check the Optional Feeder Drive
signal.
1.Disconnect P/J422 from the
Optional Feeder Board.
2.Is there +24 V across ground <=>
J422-6 pin on the Optional Feeder
Board when the Interlock Switch is
activated?
Replace the
550-Sheet
Feeder
(page 8-116).
Go to step 20.
20 1. Check the wiring harness
connectors P/J419, P/J273, and P/
J27 between Optional Feeder Board
and the MCU Board.
2.Are the connectors securely
connected?
Go to step 21. Reconnect the
connectors.
21 Check the Right Side Harness for
continuity.
1.Disconnect P/J273 from the
Optional Feeder Harness.
2.Disconnect P/J27 from the MCU
Board.
3.Check continuity between P/J273
<=> P/J27.
Go to step 22. Replace the
Right Side
Harness.
22 Check the Optional Feeder Board
signal.
1.Disconnect P/J27 from the MCU
Board.
2.Is there +24 V across ground <=>
J27-B4 pin/J27-B5 pin on the MCU
Board when the Interlock Switch is
activated?
Replace the
550-Sheet
Feeder
(page 8-116).
Replace the
MCU Board
(page 8-88).
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
