Phaser 6180MFP Multifunction Printer Service Manual 3-31
Error Messages and Codes
4 1.Reseat the Tray 1 Side Guides.
2.Does the error still occur when
printing?
Go to step 5. Complete.
5 1.Perform the Registration Sensor
test (page 4-43): Service Mode >
Printer Diag > Engine Diag >
Sensor Test > Regi Sensor.
2.Does the number on the Control
Panel increase by 1 every time the
Actuator of the Registration Sensor
is activated?
Go to step 6. Go to step 10.
6 1.Perform the Tray 1 (MPT) Feed
Solenoid test (page 4-67): Service
Mode > Printer Diag > Engine Diag
> Motor Test > Tray 1 (MPT) Feed
Solenoid.
2.Does the Solenoid operate properly?
Go to step 7. Go to step 15.
7 1.Perform the Tray 1 (MPT) Turn
Clutch test (page 4-66): Service
Mode > Printer Diag > Engine Diag
> Motor Test > Tray 1 (MPT) Turn
Clutch.
2.Does the Clutch operate properly?
Go to step 8. Go to step 18.
8 1.Perform the Tray 2 Motor test
(page 4-56): Service Mode >
Printer Diag > Engine Diag > Motor
Test > Tray 2 Motor.
2.Does the Motor operate properly?
Go to step 9. Go to step 21.
9 1.Check the following for evidence of
fault or damage:
â– Retard Roll, PL2.1.7
â– MPT Feed Roll, PL3.1.10
2.Is the part damaged?
Replace the
MCU Board
(page 8-88).
Replace the
defective
part(s).
â– Retard Roll
(page 8-15)
â– MPT Feed
Roll
(page 8-13)
10 1. Check the wiring harness
connectors P/J23, P/J232, and P/
J2322 between the MCU Board and
the Registration Sensor.
2.Are the connectors securely
connected?
Go to step 11. Reconnect the
connectors.
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No
To Next Page
