3-38 Phaser 6180MFP Multifunction Printer Service Manual
Error Messages and Codes
6 1.Perform the Main Motor test
(page 4-54): Service Mode >
Printer Diag > Engine Diag > Motor
Test > Main Motor.
2.Does the Motor operate properly?
Go to step 7. Go to step 22.
7 1.Perform the Sub Motor test
(page 4-55): Service Mode >
Printer Diag > Engine Diag > Motor
Test > Sub Motor.
2.Does the Motor operate properly?
Go to step 8. Go to step 25.
8 1.Perform the Tray 2 Motor test
(page 4-56): Service Mode >
Printer Diag > Engine Diag > Motor
Test > Tray 2 Motor.
2.Does the Motor operate properly?
Go to step 9. Go to step 28.
9 1.Perform the Regi Clutch test
(page 4-65): Service Mode >
Printer Diag > Engine Diag > Motor
Test > Regi Clutch.
2.Does the Clutch operate properly?
Go to step 10. Go to step 31.
10 1. Check the Fuser.
2.Are there any remaining paper or
debris in the Fuser?
Remove the
debris.
Go to step 11.
11 1.Check the Regi Rubber Roll and
Regi Metal Roll for damages and
correct installation.
2.Are the rollers correctly installed?
3.Are there any damages on the
rollers?
Go to step 12. Replace the
Feeder Unit
(page 8-47).
12 1.Check the Transfer Unit for correct
installation. Reseat the Transfer Unit
(page 8-9).
2.Does the error still occur when
printing?
Replace the
MCU Board
(page 8-88).
Complete.
13 1. Check the wiring harness
connectors P/J17 and P/J171
between the MCU Board and the
Fuser.
2.Are the connectors securely
connected?
Go to step 14. Reconnect the
connectors.
14 Check the Fuser Harness for
continuity.
1.Disconnect P/J17 from the MCU
Board.
2.Disconnect P/J171 from the Fuser.
3.Check continuity between P/J17 <=>
P/J171.
Go to step 15. Replace the
Fuser Harness.
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No
To Next Page
