Xerox Phaser 6180MFP Service Manual

3-62 Phaser 6180MFP Multifunction Printer Service Manual
Error Messages and Codes
9 Check the Print Cartridge Sensor for
operation.
1.Measure the voltage across:
■ Ground <=> P/J19-3 pin (Yellow)
■ Ground <=> P/J19-6 pin
(Magenta)
■ Ground <=> P/J19-9 pin (Black)
■ Ground <=> P/J19-12 pin (Cyan)
2.Does the voltage change when the
paper is inserted into the sensor
detecting point?
Replace the
MCU Board
(page 8-88).
Replace the
Print Cartridge
Sensor:
■ Black
(page 8-57)
■ Yellow/
Magenta/Cyan
(page 8-58)
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
