Xerox Phaser 6180MFP Service Manual

Phaser 6180MFP Multifunction Printer Service Manual 3-123
Error Messages and Codes
4 Check the Duplex Unit Harness for
continuity.
1.Disconnect P/J428 from the Duplex
Board.
2.Disconnect P/J2720 from the Front
Cover Harness.
3.Check continuity between P/J2720
<=> P/J428.
Go to step 5. Replace the
Duplex Unit
Harness.
5 Check the Front Cover Harness for
continuity.
1.Disconnect P/J2720 and P/J272.
2.Check continuity between P/J2720
<=> P/J272.
Go to step 8. Replace the
Front Cover
Harness.
6 Check the Right Side Harness for
continuity.
1.Disconnect P/J272 from the Front
Cover Harness.
2.Disconnect P/J27 from the MCU
Board.
3.Check continuity between P/J27 and
P/J272.
Go to step 7. Replace the
Right Side
Harness.
7 1.Replace the Duplex Unit
(page 8-115).
2.Does the error still occur?
Replace the
MCU Board
(page 8-88).
Complete.
8 1.Reconnect the wiring harness
connectors.
2.Does the error still occur when the
printer is turned On?
Go to step 4. Complete.
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
