Xerox Phaser 6180MFP Service Manual

Phaser 6180MFP Multifunction Printer Service Manual 3-129
Error Messages and Codes
5 1.Check the Main Drive for correct
installation.
2.Is the Main Drive correctly installed?
Go to step 6. Reseat the Main
Drive
(page 8-75).
Go to step 6.
6 Does the error still occur when the
printer is turned On?
Go to step 7. Complete.
7 Check the Right Side Harness for
continuity.
1.Disconnect P/J22 from the MCU
Board.
2.Disconnect P/J221 from the Drive
Assembly.
3.Check continuity between P/J22 <=>
P/J221.
Go to step 8. Replace the
Right Side
Harness.
8 Check the Main Drive signal.
1.Disconnect P/J22 from the MCU
Board.
2.Is there +24 V across ground <=>
J22-A2/J22-A4 pin when the
Interlock Switch is activated?
Replace the
Main Drive
(page 8-75).
Replace the
MCU Board
(page 8-88).
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
