3-158 Phaser 6180MFP Multifunction Printer Service Manual
Error Messages and Codes
4 Check the AIO-ESS Harness for
continuity.
1.Disconnect P/J48 from the Scanner
Controller Board.
2.Disconnect P/J480 from the Image
Processor Board.
3.Check continuity between P/J48 <=>
P/J480.
Go to step 5. Replace the
AIO-ESS
Harness
Assembly.
5 1.Replace the Scanner Controller
Board (page 8-99).
2.Does the error still occur when
copying?
Replace the
Processor Board
(page 8-90).
Complete.
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No
