Xerox Phaser 6180MFP Service Manual

3-194 Phaser 6180MFP Multifunction Printer Service Manual
Error Messages and Codes
■ Chain Link 133-278: Fax Error (File Erase Error)
■ Chain Link 133-279: Fax Error (Maximum Reception Lines Over)
■ Chain Link 133-280: Fax Error (EER_FAX_TIME)
■ Chain Link 133-282: Fax Error (Memory Pool Get Error)
■ Chain Link 133-283: Fax Error (Message Send Error)
■ Chain Link 133-286: Fax Error (OS Call Error)
■ Chain Link 133-287: Fax Error (File Open Error)
■ Chain Link 133-288: Fax Error (File Close Error)
■ Chain Link 133-289: Fax Error (File Erase Error)
■ Chain Link 133-290: Fax Error (Print Decode Error)
Initial Actions
■ Cycle printer power.
■ If the problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Scanner Controller Board, PL9.1.1
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 1.Turn the printer power Off and back
On.
2.Does the error still occur?
Go to step 2. Complete.
2 1.Check the Country setting
information on the Control Panel:
System > Admin Menu > Fax
Settings > Country.
2.Is the Country setting correct?
Go to step 3. Change the
Country Setting
to the correct
country.
3 1.Check the Scanner Controller Board
for correct installation. Reseat the
Scanner Controller Board
(page 8-99).
2.Does the error still occur when the
printer is turned On?
Replace the
Scanner
Controller Board
(page 8-99).
Complete.

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
