Xerox Phaser 6180MFP Service Manual

Phaser 6180MFP Multifunction Printer Service Manual 4-93
General Troubleshooting
8 1.Manually dial any local phone number
using touch tone with the outside line
prefix (i.e., 9).
2.Is there a connection?
Go to step 3. Go to step 9.
9 1.Check for the pulse. Manually dial using
pulse 20PPM.
2.Is there a connection?
Go to step 3. Set pulse to
10PPM.
Go to step 3.
10 1. Receive a fax from another fax machine.
2.Did the reception complete?
Complete.
Connect
additional
devices such
as external
telephone and
answering
machine.
1.Check the
Secure
settings:
System >
Admin
Menu >
Secure
Settings >
Secure
Receive.
2.Is Secure
Rcv. Set
Disable?
(the default
setting is
Disable)
11 1. Check the Fax setting: System > Admin
Menu > Fax Settings > Ans Select.
2.Is the Ans Select setting correct?
Go to step 12. Correct the
setting. Refer
to “Fax
Configuration
Settings” on
page 4-99 for
detailed
information.
12 1. Check the Auto Answer Fax value:
System > Admin Menu > Fax Settings >
Auto Answer Fax.
2.Does the value exceed 30?
Set the value
to below 30.
Replace the
Scanner
Controller
Board
(page 8-99).
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
