Xerox Phaser 6180MFP Service Manual

Phaser 6180MFP Multifunction Printer Service Manual 5-45
Print-Quality Troubleshooting
4 1.Check for any debris on the
document glass and the CVT
window.
2.Are there any debris?
Remove the
debris.
Go to step 5.
5 1.Check the Scanner Controller Board
wiring harness connectors P/J64
and P/J65. Reseat the connectors.
2.Does the image quality improve?
Complete. Go to step 6.
6 1.Check for spot’s regular intervals.
2.Are there any spots on the page?
Refer to
“Repeating
Defect
Measurement”
on page 5-24.
Go to step 7.
7 1.Check the Print Cartridge (C/M/Y/K)
for damages.
2.Is the Print Cartridge damaged?
Replace the
Print Cartridge
(page 8-11).
Go to step 8.
8 1.Check the Transfer Unit.
2.Are there any damages on the
Transfer Unit surface?
Replace the
Transfer Unit
(page 8-9).
Go to step 9.
9 1.Check the Transfer Unit for correct
installation. Reseat the Transfer Unit
(page 8-9).
2.Does the image quality improve?
Complete. Go to step 10.
10 1.Check the paper path.
2.Are there any toner contaminations
on the paper path?
Clean the paper
path.
Go to step 11.
11 1. Check the Fuser for correct
installation. Reseat the Fuser
(page 8-12).
2.Does the image quality improve?
Complete. Replace the
Print Cartridge
(page 8-11).
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
