Phaser 6180MFP Multifunction Printer Service Manual 5-51
Print-Quality Troubleshooting
3 1.Check the Transfer Unit.
2.Are there any damages on the
Transfer Unit surface?
Replace the
Transfer Unit
(page 8-9).
Go to step 4.
4 1.Check the Transfer Unit for correct
installation. Reseat the Transfer Unit
(page 8-9).
2.Does the image quality improve?
Complete. Go to step 5.
5 1.Check the Print Cartridge (C/M/Y/K)
for correct installation. Reseat the
Print Cartridge (page 8-11).
2.Does the image quality improve?
Complete. Go to step 6.
6 1.Replace the Fuser (page 8-12).
2.Does the image quality improve?
Complete. Go to step 7.
7 1.Replace the Print Cartridge
(page 8-11).
2.Does the image quality improve?
Complete. Replace the
Processor
Board
(page 8-90).
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No
To Next Page
