Xerox Phaser 6180MFP Service Manual

5-56 Phaser 6180MFP Multifunction Printer Service Manual
Print-Quality Troubleshooting
17 1. Replace the Tray 1 (MPT) Feed
Roller (page 8-13).
2.Does the error still occur?
Replace the Tray
1 (MPT) Retard
Holder
(page 8-38).
Complete.
18 1.Check the skewed mode through the
Duplex Unit.
2.Is the skewed paper fed the from the
Duplex?
Go to step 19. Go to step 21.
19 1.Check the Duplex Unit for correct
installation. Reseat the Duplex Unit
(page 8-115).
2.Does the error still occur?
Go to step 20. Complete.
20 1.Check the paper path.
2.Are there any debris on the paper
path?
Remove the
debris.
Replace the
Duplex Unit
(page 8-103).
21 1. Check the paper tray for correct
installation. Reseat the tray.
2.Does the error still occur?
Go to step 22. Complete.
22 1. Check the paper for correct
placement. Reseat the paper in the
tray.
2.Does the error still occur?
Go to step 23. Complete.
23 1. Check the paper tray Side Guides.
Reset the Side Guides.
2.Does the error still occur?
Go to step 24. Complete.
24 1.Check the paper path.
2.Are there any debris on the paper
path?
Remove the
debris.
Go to step 25.
25 1.Replace the Feed Roller (Tray 2,
page 8-14) (Tray 3, page 8-16).
2.Does the error still occur?
Replace the
Retard Roller
(Tray 2,
page 8-15) (Tray
3, page 8-17).
Complete.
Troubleshooting Procedure Table (continued)
Step Action and Questions Yes No
