8-32 Phaser 6180MFP Multifunction Printer Service Manual
Service Parts Disassembly
7. Release the Control Panel forward away from the Front Cover. Disconnect
the Control Panel connector P/J220 and remove the Control Panel.
s6180mfp-249
P/J220
