Xerox Phaser 6180MFP Service Manual

Phaser 6180MFP Multifunction Printer Service Manual 9-7
Parts List
Parts List 1.2 Covers (2 of 2)
ID No. Name/Description Part Number
1. Cover Assy Front (with 3-12, 17-23, 26, 34, 36) 848K07713
2. Control Panel (without overlays) 848K05082
3. Cover Front Assy
4. Latch Front
5. Plate Latch
6. Spring Latch
7. Cover Harness
8. Button Top
9. Contact Front
10. Shaft Pivot (Pin Kit) 675K47432
11. Cover Harness
12. Holder Drawer
13. Harness Assy Front Cover (J272-P2720, P2721, T4322-T43221) (Harness Kit) 604K44680
14. Harness Assy Drawer Earth (T4321-T43210)
15. Harness Assy Front Cover Earth 1 (T4321-T43210)
16. -----
17. Pin Pivot PMT (Pin Kit) 675K47432
18. Shaft Lever
19. Plate Pivot
20. Lever MPT 1
21. Spring Lever MPT
22. Spring Lever Link
23. Lever MPT 2
24. Harness Assy A-OP-OPP (J202-J5301) (Harness Kit) 604K44680
25. Harness Assy A-OP-ESS (J53-P5301) (Harness Kit) 604K44680
26. Cover Assy MPT (with 27-32) 848K02012
27. Link Assy MPT Left
28. Tray Assy MPT Base
29. Link Assy MPT Right
30. Tray MPT
31. Spring Tray
32. Cover MPT
33. Shaft Pivot MPT (Pin Kit) 675K47432
34. Spring
35. -----
36. Cover OPP Left
37. Plate Earth FC
38. Dup Connector Cap
Kit Cap Connector Drawer

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
