Xerox Phaser 6180MFP Service Manual

9-16 Phaser 6180MFP Multifunction Printer Service Manual
Parts List
Parts List 3.2 Paper Feeder (2 of 2)
ID No. Name/Description Part Number
1. Kit Feeder Assy (with 1, PL3.2.1, 19-20) 675K47544
2. Chute Assy Regi (with 3-21, 60)
3. Bracket NIP
4. Spring Regi Left
5. Spring Regi Right
6. Roll Regi Metal
7. Roll Regi Rubber
8. Film Inlet Left
9. Gear Regi Metal
10. Gear Regi Rubber
11. Bearing Regi
12. Chute Regi
13. Actuator A
14. Spring Regi Sensor A
15. Actuator B
16. Spring Regi Sensor B
17. Cover Actuator
18. Chute Separator BTM
19. Clamp Mini-Saddle
20. Clamp
21. Bearing Regi E
22. -----
23. -----
24. -----
25. Clutch Assy PH Turn
26. Bearing Nudger
27. Spring Earth
28. Chute Assy Regi Upper (with 29, 30)
29. Chute Regi Upper
30. Sensor Photo (Regi Sensor, Tray No Paper Sensor)
31. -----
32. Roll Assy Turn
33. Chute Assy Top (with 30, 34, 35)
34. Holder No Sensor
35. Chute Assy Separator
36. Clamp
37. Harness Assy Regi Sensor (J232-J2321, J2322) - (Harness Kit) 604K44690
38. -----
39. -----
40. -----
