Xerox Phaser 6180MFP Service Manual

9-38 Phaser 6180MFP Multifunction Printer Service Manual
Parts List
Parts List 12.1 Duplex
ID No. Name/Description Part Number
1. Kit Duplex Module (with 2-7, 9-20, 22-26) 675K47079
2. Stopper Latch Pivot
3. Handle Latch Duplex
4. Latch Duplex
5. Holder Main
6. Spring Chute Duplex
7. Bracket Holder Duplex
8. -----
9. Actuator Duplex
10. Spring Sensor Duplex
11. Holder Sensor Duplex
12. Sensor Photo (Duplex Jam Sensor)
13. Harness Assy Duplex Sensor (J430-J4301)
14. Clamp Mini
15. PWBA Duplex
16. Cover PWBA Duplex
17. Cover Connect Duplex
18. Harness Assy Duplex Unit (J428-J2711)
19. Holder Connect Duplex
20. Spring Connect Duplex
21. -----
22. Bracket Fan Duplex
23. Cover Harness Fan
24. Cover Harness Chute
25. Fan Duplex
26. Seal Duplex
27. Cover Chute Duplex
