10-18 Phaser 6180MFP Multifunction Printer Service Manual
Plug/Jack and Wiring Diagrams
Denotes a Photo Sensor.
Denotes an LED.
Denotes a Safety Interlock Switch.
Denotes an On-Off Switch (single-pole, single-
throw switch).
Denotes an On-Off Switch (Temperature -
normally close).
Denotes an NPN Photo-transistor.
Represents an interconnection between parts
using wiring harness or wire.
Represents an interconnection which differs
according to the specifications.
Symbol
Description
Optic Sensor
LED
Safety Interlock Switch
On Off Switch
Temperature Switch
NPN Phototransistor
Interconnection
Interconnection, Differing
To Next Page
