NUMBER COMPONENT DESCRIPTION
1 Paper Jam Error Indicator This indicator lights when a paper
jam occurs in the Inserter.
2 Curl Up/Down Indicators Similar to the Interface Decurler
Module (IDM), these indicators
show the direction of the curl
correction. However, there are only
three curl correction options for the
Inserter:
• One upward curl correction; this
is the top indicator.
• One downward curl correction;
this is the bottom indicator.
• Off (no curl correction); this is
the middle indicator.
Important: Use one of the following buttons only if paper curl continues after setting the curl correction
level to the highest or lowest setting on the Interface Decurler Module (IDM).
3 Manual Curl Up Button When the printed output is curled
upwards, select the curl-up button.
4 Manual Curl Down Button When the printed output is curled
downwards, select the curl-down
button.
5 Auto Curl Button Automatically corrects the paper
curl by selecting the curl direction
and amount.
Paper and Media for Inserter Tray T1
Tip: Paper fed from the Inserter device is not printed on; however, the paper is placed into the printed output at
selected locations.
Supported Paper for the Inserter Tray T1
PAPER SIZE PAPER WEIGHT TRAY CAPACITY
182 x 148– 30 x 488 mm (7.2 x
5.8–13 x 19.2 in.), A3
52–400 g/m
2
coated and uncoated 250 sheets, based on Colotech+90
Note: When the Inserter Tray is filled with 8.5 in. wide (SEF) media, its default size is 8.5 x 14 in. If you insert
8.5 x 11 in. media, it is necessary to use Admin Mode Tools to adjust the default value of NVM 769-503. For
more information, refer to the System Administrator Guide.
When you combine the following paper types with saddle stitch or bi-fold, use Tray 5 (Bypass):
182
