TRAYS PAPER SIZES WEIGHTS
Extra Long Sheet (XLS) Feeder Standard:
• Maximum: SRA3 (320 x 450
mm),
320 x 488 mm (12.6 x 19.2
in.)
• Minimum: A4 (210 x 297
mm), 8.3 x 11.7 in.
52–400 g/m
2
Custom:
• Width: 210–330.2 mm (8.2–
13 in.)
• Length: 210–1200 mm (8.2–
47.2 in.)
* If the press is equipped with a Dual High Capacity XLS Vacuum Feeder, the Tray 5, bypass tray, is installed on
the second HCVF.
HHiigghh CCaappaacciittyy XXLLSS VVaaccuuuumm FFeeeeddeerr TTrraayy CCaappaacciittyy
• Tray 5, Bypass Tray: 250 sheets
• HCVF Tray 7 or Dual HCVF Trays 6, 7, and 9: 2100 sheets for each tray
• Extra Long Sheet (XLS) Feeder: 700 sheets
Note: The values are based on 90 g/m
2
paper.
Paper and Media for High Capacity XLS Vacuum Feeder
Important:
• Loading paper above the maximum fill line can cause paper jams or device malfunctions.
• Position the guides correctly to match the paper size. Incorrectly positioned guides can cause misfeeds and
paper jams.
• When the power is reconnected while the bottom plate of the tray is rising, it is possible that the plate does not
continue to move up. In this case, pull out the tray, ensure that the plate lowers fully, then push the tray into the
machine slowly and firmly.
Note: When paper sheets are loaded or fed, the tray makes a sound of supplying air. This sound is caused by
the Air Assist function and not an abnormal noise.
Loading Paper in the High Capacity XLS Vacuum Feeder (HCVF) Trays
Important: If fewer than 100 sheets of paper are loaded, the tray guides apply too much pressure to the
paper, which causes the paper to be skewed. Skewed paper leads to paper jams.
150
Xerox
®
Versant
®
280 Press User Documentation
