CHAPTER18 Core Entities
Mediant 1000 Gateway & E-SBC | User's Manual
7. Configure the address of the Proxy Set according to the parameters described in the table
below.
8. Click Apply.
Table 18-6: Proxy Sets Table and Proxy Address Table Parameter Description
Parameter Description
'SRD'
voip-network
proxy-set > srd-
id
[ProxySet_SRDName]
Assigns an SRD to the Proxy Set.
Note:
■ The parameter is mandatory and must be configured first before
you can configure the other parameters in the table.
■ To configure SRDs, see Configuring SRDs.
General
'Index'
configure voip >
voip-network
proxy-set
[ProxySet_Index]
Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
'Name'
proxy-name
[ProxySet_ProxyName]
Defines a descriptive name, which is used when associating the
row in other tables.
The valid value is a string of up to 40 characters.
Note:
■ Each row must be configured with a unique name.
■ The parameter value cannot contain a forward slash (/).
'Gateway IPv4 SIP
Interface'
gwipv4-sip-int-
name
[ProxySet_
GWIPv4SIPInterfaceN
ame]
Assigns an IPv4-based SIP Interface for Gateway calls to the
Proxy Set.
Note:
■ At least one SIP Interface must be assigned to the Proxy Set.
■ The parameter appears only if you have configured a network
interface with an IPv4 address in the IP Interfaces table (see
Configuring IP Network Interfaces).
■ To configure SIP Interfaces, see Configuring SIP Interfaces.
- 368 -
