Avaya Definity SI - Page 181

ATM Tips
Issue 4 May 2002
5-77555-233-123
Screen 5-11. Screen output for display circuit-packs 1
Screen 5-12. Screen output for display circuit-packs 2
4. Enter display atm pnc portnetwork on the DEFINITY SAT.
This display tells you the ATM addresses that have been administered for
each TN230X. Verify that each ATM address (the concatenation of the five
displayed hexadecimal fields) is correct and match those administered in
the A500. See ‘‘A500 Administration’’ for more information.
display circuit-packs 1
CIRCUIT PACKS
Cabinet: 1 Carrier: A
Cabinet Layout: five-carrier Carrier Type: processor
*** PROCESSOR BOARDS NOT ADMINISTERABLE IN THIS SCREEN ***
CIRCUIT PACKS
Cabinet: 1 Carrier: B
Cabinet Layout: five-carrier Carrier Type: port
Slot Code Sfx Name Slot Code Sfx Name
00: 11: TN464 C DS1 INTERFACE
01: 12: TN464 F DS1 INTERFACE
02: TN2305 ATM PNC EI 13: TN767 F DS1 INTERFACE
03: 14: TN767 C DS1 INTERFACE
04: TN754 C DIGITAL LINE 15: TN760 D TIE TRUNK
05: TN746 B ANALOG LINE 16: TN760 D TIE TRUNK
06: TN753 DID TRUNK 17:
07: TN771 D MAINTENANCE/TEST 18:
08: TN747 B CO TRUNK 19:
09: TN556 B BRI LINE 20:
10: TN767 C DS1 INTERFACE
’#’ indicates circuit pack conflict.
display circuit-packs 2
CIRCUIT PACKS
Cabinet: 2 Carrier: A
Cabinet Layout: single-carrier-stack Carrier Type: expansion-control
Slot Code Sfx Name Slot Code Sfx Name
11: TN746 B ANALOG LINE
01: TN2305 ATM PNC EI 12:
02: 13:
03: 14:
04: 15:
05: 16:
06: 17: TN754 C DIGITAL LINE
07:
08:
09: TN767 E DS1 INTERFACE
10: TN754 B DIGITAL LINE
’#’ indicates circuit pack conflict.
