Avaya Definity SI - Page 182

Routine Maintenance Procedures
555-233-123
5-78 Issue 4 May 2002
Administered with hard coded PNNI routes
If the port networks are addressed using hard coded PNNI routes in the
A500, the display looks like Screen 5-13 (pnc 1) and Screen 5-14 (pnc 2).
Screen 5-13. Screen output for display atm pnc 1
Screen 5-14. Screen output for display atm pnc 2
Administered with End System Identifiers
If the port networks are addressed using End System Identifiers, the
display looks like Screen 5-15 on page 5-79 (pnc 1) and Screen 5-16 on
page 5-79 (pnc 2).
display atm pnc 1
ATM PNC
Connection Number: 1
Location: 01B02
Name:
Address Format: ICD ATM
AFI: 47
ICD: 0005
HO-DSP: 80FFE1000000F2071B02
ESI: 000000000000
SEL: 00
display atm pnc 2
ATM PNC
Connection Number: 2
Location: 02A01
Name:
Address Format: ICD ATM
AFI: 47
ICD: 0005
HO-DSP: 80FFE1000000F2072A01
ESI: 000000000000
SEL: 00
