MAPD-BD (MAPD Interface Circuit Pack TN802)
Issue 4 May 2002
10-1043555-233-123
Support for laptop PCs
Field technicians can access the TN802 circuit pack through:
1. ‘‘pcANYWHERE client software’’
2. ‘‘Directly-connected keyboard, monitor, and mouse’’
pcANYWHERE client software
1. Attach a male-to-male serial cable and a NULL modem connector (if not
built into the cable you use) to the COM2 connector (Note 8 in Figure 10-65
on page 10-1044) Attach the other end to the serial port of your laptop.
2. Launch the pcANYWHERE application.
3. Click on Add Remote Control Item.
4. In the Properties window, choose the communication port to which you
connected the cable in Step 1.
5. Click on Details and configure the settings (Table 10-380):
Table 10-379. TN802 LCD messages for IP trunks
Display Explanation
PC BOOT The TN802 MAPD PC is booting up.
IP TRK # IP Trunk application is running (# character blinks)
IML DWN # Internal error on the IP Trunk. System shuts down
and sends and error message to the board.
MSHUT # where both MSHUT
and # are blinking
The system is in the process of shutting down due to
a front panel button press. DO NOT attempt to
remove board.
MSHUT #, where # is blinking The system has shut down gracefully.
Table 10-380. Remote connection settings
Field Value
Speed
38,400
Parity
None
Flow Control
RTS/CTS
Started by
Carrier detect (DCD)
Ended by
Carrier detect (DCD)
