Maintenance Architecture
555-233-123
1-4 Issue 4 May 2002
7. Find the DID-TRK MO in the Maintenance Object chapter of the
appropriate maintenance book.
8. In the first table look up the initial command to run in the MAJOR row of the
table (Step 4 indicated that a DID trunk in slot 10, carrier C has a MAJOR
alarm).
9. Type test port 01C1008 long and press
Enter.
“01C1008” is the address of the alarmed port (Screen 1-2 on page 1-3 and
Screen 1-3 on page 1-3)
10. While the port test is running, look up the Error Type (1537 from Screen
1-3) in the DID Trunk Error Log Entries table (example below).
11. Since the Test to Clear Value (
test port 01C1008 sh r 1) is very similar to the
initial test you ran in Step 11, wait for the results of the port test.
12. When the port test finishes, the following screen appears (Screen 1-4):
Screen 1-4. Test Results screen
13. Find the Port Diagnostic Test (#35 from Test No.) in the DID-TRK section
of the Maintenance book. Note the Error Code (61472).
MO Name (in
Alarm Log) Alarm Level Initial Command to Run
1
1. UU is the universal cabinet number (1 for PPN, 2 - 44 for EPNs), C is the carrier designation (A, B,
C, D, or E), SS is the number of the slot in which the circuit pack resides (01 to 21), and pp is the
two digit port number (01, 02,...).
Full Name of MO
DID-TRK MAJOR
2
2. A MAJOR alarm on a trunk indicates that alarms on these trunks are downgraded by the set options
command and that at least 75% of the trunks in this trunk group are alarmed.
test port UUCSSpp long DID Trunk
DID-TRK MINOR test port UUCSSpp long DID Trunk
DID-TRK WARNING test port UUCSSpp DID Trunk
Table 1-2. DID Trunk Error Log entries
Error
Type
Aux
Data Associated Test Alarm Level
On/Off
Board Test to Clear Value
1537 Port Diagnostic (#35) MAJ/MIN/WRN OFF test port UUCSSpp sh r 1
3840(k) 40965 None
TEST RESULTS
Port Maintenance Name Alt. Name Test No. Result Error Code
01C1008 DID-TRK 35 FAIL 61472
