ANL-24-L (24-Port Analog Line)
Issue 4 May 2002
10-59 555-233-123
FAIL The terminal equipment is not connected to the circuit pack.
Some terminal equipment, such as modems, may fail even
when connected properly.
1. Remotely test the equipment.
2. If the test fails again, look for RING-GEN errors in the
error log. If present, refer to “RING-GEN”.
3. Check all of the wiring between the station equipment and
the switch. Then, run the test again.
4. If the test still fails, the set may be defective. Check the
set, and replace it, if necessary.
5. Some terminal equipment could fail even when it is
connected properly. If this is the case, disable the test
using the change station extension command (enter n
into the
Test field). Note that this action also disables
tests 6, 7, 161, and 35 on this port.
PASS The station is connected properly to the switch. This test may
also pass if no terminal equipment is connected and the
terminal is located very far from the switch. User-reported
troubles on this port should be investigated by using other port
tests, by examining station wiring, or by examining the station.
0NO
BOARD
The test could not relate the internal ID to the port (no board).
This could be due to incorrect translations, no board is
inserted, an incorrect board is inserted, or an insane board is
inserted.
1. Check to ensure that the board translations are correct.
Use the list config command, and resolve any problems.
2. If the board was found to be correctly inserted in step 1,
issue the busyout board command.
3. Issue the reset board command.
4. Issue the release busy board command.
5. Issue the test board long command. This should
re-establish the linkage between the internal ID and the
port. If this is not the case, check to ensure that there is a
valid board inserted.
Table 10-22. TEST #48 Station Present Test — Continued
Error
Code
Te s t
Result
Description/Recommendation
Continued on next page
