ASAI-PT
Issue 4 May 2002
10-187 555-233-123
Level 1 Status Inquiry Test (#621)
This test determines the state of the transmission facility of a BRI port at the
Level 1 (L1) or physical layer. L1 can be in one of two possible states: Activated or
Deactivated.
The Activated state is the correct state for an ISDN-BRI port. In this state the
Level 1 interface can communicate with the BRI endpoint or ASAI adjunct
administered on this port. This test passes if the state of L1 is activated. This test
also passes if software has taken this port out of service.
The Deactivated state indicates a problem with the ASAI circuit pack. When in this
state, the Level 1 interface is idle and is not trying to communicate with the BRI
endpoints or adjunct. When an ASAI port is placed in the out-of-service state,
Level 1 is also put into the deactivated state. This could be due either to the
system detecting a fault with the port or in response to a busyout port PCSSpp
request.
2100 ABORT Could not allocate the necessary system resources to run this
test.
1. Retry the command at 1-minute intervals a maximum of 5
times.
FAIL The Looparound test has failed.
1. If the test fails repeatedly, attempt to reset the circuit pack
if the other ports on the board are not in use. Reset the
circuit pack by issuing the busyout board PCSS and the
reset board PCSS commands.
2. If the test fails again, execute test pkt P on the
management terminal. If this fails, follow the failure
procedures the in PKT-BUS section.
3. If the tests executed in Step 2 pass, the problem is local to
the BRI board. Replace the circuit pack.
PASS The BRI Port Local LAN Looparound test has passed.
Table 10-60. TEST #618 BRI Port Local LAN Looparound — Continued
Error
Code
Te s t
Result Description/Recommendation
Continued on next page
