Datalogic Magellan 9800i User Manual

Product Reference Guide 163
Chapter 11
Interface Related Features
Interface Type
Specifies the current scanner interface. Selections are:
INTERFACE (I/F)
TYPE
I/F I.D.
NU
MBER
a
a. To access a scanner’s interface
identification number, place the scanner in Scanner Diagnostic
Mode and view the 7-segment FRU display (reference
Chapter 2, Diagnostic Modes, for
more information).
RS-232 Standard 05
RS-232 Wincor-Nix-
dorf
12
RS-232 Single Cable 20
USB OEM 45
IBM
Port 17
04
IBM
Port 5B
08
IBM
Port 9B
23
USB Keyboard 35
USB-TEC 0D
USB COM 47
NOT USER-SELECTABLE
System Interface
7-segment FRU
display indi-
cates 0 at start-
up (
accompa-
nied by trill beep
fo
r approx. 2
seconds)

Datalogic Magellan 9800i Specifications

General

Type	Built-in bar code reader
Sensor type	-
Scanner type	1D/2D
Light levels (direct sunlight)	0 - 86080 lx
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Micro QR Code, QR Code, Small Aztec Code
Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power source type	AC
Power consumption (standby)	11 W
Power consumption (typical)	12 W
Standard interfaces	RS-232
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black, Grey
Built-in display	No

Weight and Dimensions

Weight	- g
