Enter/Exit Programming Mode
Product Reference Guide 139
Scale Intercharacter Delay
With regard to scale functions, this feature specifies a delay between the end of one character
and the beginning of the next in 10-millisecond increments.
To set the Scale Intercharacter Delay:
1. Scan the Enter/Exit Programming Mode bar code.
2. Scan the bar code below, Set Scale Intercharacter Delay. You’ll need to cover any
unused bar codes on this and the facing page to ensure that the scanner reads only the bar
code y
ou intend to scan.
3. Scan the appropriate digits from the Keypad in Appendix C that represent the desired
delay. The selectable range is 0-255, which
is the delay in 10-millisecond increments. Pad
all single and double digit numbers with leading zeroes to yield a three-digit entry (000-
255).
Examples:
001 = 10ms
005 = 50ms
040 = 400ms
100 = 1,000ms (1 second)
4. The scanner will automatically exit Programming M
ode when the appropriate amount of
digits have been scanned.
041A(CR)
Set Scale Intercharacter Delay
DEFAULT
Default setting for this feature is:
00 - No Intercharacter Delay

Datalogic Magellan 9800i Specifications

General

Type	Built-in bar code reader
Sensor type	-
Scanner type	1D/2D
Light levels (direct sunlight)	0 - 86080 lx
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Micro QR Code, QR Code, Small Aztec Code
Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power source type	AC
Power consumption (standby)	11 W
Power consumption (typical)	12 W
Standard interfaces	RS-232
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black, Grey
Built-in display	No

Weight and Dimensions

Weight	- g
