Datalogic Magellan 9800i User Manual

Enter/Exit Programming Mode
Product Reference Guide 315
Code 128 Length 2
If Code 128 Length Control is set to Fixed-Length decoding, this feature specifies Code 128
second fixed length. If Code 128 Length Control is set to Variable-Length decoding, this
feature specifies the maximum label length.
NOTE
When in Fixed Length mode, if Length 2 is set to the value of 00 (zero),
then only Length 1 will apply.
To set this feature:
1. Scan the ENTER/EXIT Programming Mode bar code.
2. Scan the barcode, Set Code 128 Length 2 below. You’ll need to cover any unused bar-
codes on this and the facing page to ensure that the scanner reads only the barcode you
intend to scan.
3. Scan the appropriate digits from the Keypad in Appendix C that represent the desired
label length. The selectable range for this option is 01 to 80. P
ad all single digit numbers
with a leading zero to yield a two-digit entry (01-80).
4. Complete the programming sequence by scanning
the ENTER/EXIT Programming
Mode bar code.
04B9(CR)
Set Code 128 Length 2
DEFAULT
Default setting for this feature = 80

Datalogic Magellan 9800i Specifications

General

Type	Built-in bar code reader
Sensor type	-
Scanner type	1D/2D
Light levels (direct sunlight)	0 - 86080 lx
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Micro QR Code, QR Code, Small Aztec Code
Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power source type	AC
Power consumption (standby)	11 W
Power consumption (typical)	12 W
Standard interfaces	RS-232
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black, Grey
Built-in display	No

Weight and Dimensions

Weight	- g
