Introduction
12
Magellan™ 9800i Scanner
Labeling
Regulatory, reference and safety labeling is shown in Figure 6.
Figure 6. Labeling
AUX
EAS
SCALE
HOST
TDR
HOST
PORT
USB
0.00
REMOTE
DISPLAY
POWER
POWER
0.00
HOST
PORT
SCALE
HOST
EAS AUX
REMOTE
DISPLAY
USB
TDR
1
2
3
4
Beneath the Platter Underside of Scanner
1
Scale Regulatory Label (units with scales
only)
3
Regulatory - I/F Label
2
Serial Number Label
4
Connector Bulkhead Label
