Enter/Exit Programming Mode
Product Reference Guide 197
RS-232 ACK NAK Retry Count
This feature sets the number of times for the scanner to retry a label transmission under a retry
condition.
To set the RS-232 ACK NAK Retry Count:
1. Scan the Enter/Exit Programming Mode bar code.
2. Scan the bar code,
Set RS-232 ACK NAK Retry Count below. You’ll need to cover any
unused bar codes on this and the facing page to ensure that the scanner reads only the bar
code y
ou intend to scan.
3. Scan the appropriate digits from the
Keypad in Appendix C that represent the desired
number. The selectable range is 000-255 resets. Pad all single and double digit numbers
with leading zeroes to yield a thr
ee-digit entry (000-255).
NOTE
A setting of 255 specifies “retry forever.”
4. The scanner will automatically exit Programming Mode when the appropriate amount of
digits have been scanned.
0608(CR)
Set RS-232 ACK NAK Retry Count
DEFAULT
Default setting for this feature is:
003 - Three retrys

Datalogic Magellan 9800i Specifications

General

Type	Built-in bar code reader
Sensor type	-
Scanner type	1D/2D
Light levels (direct sunlight)	0 - 86080 lx
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Micro QR Code, QR Code, Small Aztec Code
Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power source type	AC
Power consumption (standby)	11 W
Power consumption (typical)	12 W
Standard interfaces	RS-232
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black, Grey
Built-in display	No

Weight and Dimensions

Weight	- g
