Datalogic Magellan 9800i User Manual

Enter/Exit Programming Mode
Product Reference Guide 169
Maximum Host-Transmitted Message Length
Specifies the maximum number of data characters allowed in messages transmitted to the host.
To set the Maximum Host-Transmitted
Message Length:
1. Scan the Enter/Exit Programming Mode bar code.
2. Scan the bar code,
Set Maximum Host-Transmitted Message Length below. You’ll need
to cover any unused bar codes on this and the facing page to ensure that the scanner reads
only th
e bar code you intend to scan.
3. Scan the appropriate digits from the
Keypad in Appendix C that represent the desired
maximum host-transmitted message length. The se
lectable range is 0-249 data characters.
(Labels that are longer than this length are not read.) Pad all single and double digit num-
bers with leading zeroes to yield a three-digit entry (000-249).
NOTE
If this configuration item is set to 0 (000), there is no general length limit
imposed on data being transmitted to the host.
4. The scanner will automatically exit Programming Mode when the appropriate amount of
digits have been scanned.
06B1(CR)
Set Maximum Host-Transmitted Message Length
DEFAULT
Default setting for this feature is:
000 - No general limit imposed

Datalogic Magellan 9800i Specifications

General

Type	Built-in bar code reader
Sensor type	-
Scanner type	1D/2D
Light levels (direct sunlight)	0 - 86080 lx
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Micro QR Code, QR Code, Small Aztec Code
Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power source type	AC
Power consumption (standby)	11 W
Power consumption (typical)	12 W
Standard interfaces	RS-232
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black, Grey
Built-in display	No

Weight and Dimensions

Weight	- g
