Datalogic Magellan 9800i User Manual

Enter/Exit Programming Mode
378 Magellan™ 9800i Scanner
Micro PDF 417 128 Emulation
This feature specifies which AIM ID to use for Micro PDF 417 labels when performing Code
128 or EAN 128 emulation.
To set this feature:
1. Scan the Enter/Exit Programming Mode bar code.
2. Scan the bar code below for the desired setting. You’ll need to cover any unused bar codes
on this and
the facing page to ensure that the scanner reads only the bar code you intend
to scan.
3. Complete the programming sequence by scanning the
Enter/Exit Programming Mode bar
code.
DEFAULT
032700(CR)
Micro PDF 417 128 Emulation = Micro PDF AIM ID and
label type when emulating EAN128 or Code 128
032701(CR)
Micro PDF 417 128 Emulation = Code 128 / EAN128 AIM ID
and label type when emulating EAN128 or Code 128

Datalogic Magellan 9800i Specifications

General

Type	Built-in bar code reader
Sensor type	-
Scanner type	1D/2D
Light levels (direct sunlight)	0 - 86080 lx
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Micro QR Code, QR Code, Small Aztec Code
Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power source type	AC
Power consumption (standby)	11 W
Power consumption (typical)	12 W
Standard interfaces	RS-232
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black, Grey
Built-in display	No

Weight and Dimensions

Weight	- g
