Datalogic Magellan 9800i User Manual

Enter/Exit Programming Mode
372 Magellan™ 9800i Scanner
PDF 417 Length Control
Fixed Length Decoding — When fixed length decoding is enabled, the scanner will decode a bar
code if the label length matches one of the configurable fixed lengths.
Variable Length Decoding — When variable length decoding is enabled, the scanner will
decode a ar code if the label length falls in the range of the configurable minimum and
maximum length.
Configuring Fixed Length Decoding:
1. Scan the ENTER/EXIT Programming Mode bar code.
2. Scan the Fixed Length Decoding bar code.
3. Scan the ENTER/EXIT Programming Mode bar code.
4. Set Length 1 to the first fixed length using the
PDF 417 Length 1, Length 2 Program-
ming Instructions
that follow this page.
5. Set Length 2 to the second fixed length (or to ‘00
00’ if there is only one fixed length)
using the
PDF 417 Length 1, Length 2 Programming Instructions.
Configuring Variable Length Decoding:
1. Scan the ENTER/EXIT Programming Mode bar code.
2. Scan the Variable Length Decoding bar code.
3. Scan the ENTER/EXIT Programming Mode bar code.
4. Set Length 1 to the minimum length using the
PDF 417 Length 1, Length 2 Program-
ming Instructions
that follow this page.
5. Set Length 2 to the maximum length using the
PDF 417 Length 1, Length 2 Program-
ming Instructions
.
DEFAULT
05A300(CR)
PDF 417 Length Control = Variable Length
05A301(CR)
PDF 417 Length Control = Fixed Length

Datalogic Magellan 9800i Specifications

General

Type	Built-in bar code reader
Sensor type	-
Scanner type	1D/2D
Light levels (direct sunlight)	0 - 86080 lx
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Micro QR Code, QR Code, Small Aztec Code
Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power source type	AC
Power consumption (standby)	11 W
Power consumption (typical)	12 W
Standard interfaces	RS-232
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black, Grey
Built-in display	No

Weight and Dimensions

Weight	- g
