Datalogic Magellan 9800i User Manual

Enter/Exit Programming Mode
Product Reference Guide 167
IBM Interface Selection
Remember to cover any unused bar codes on this and the facing page to ensure that the scanner
reads only the bar code you intend to scan.
CAUTION
NOTE
000104(CR)
Interface Type = IBM Port 17
000108(CR)
Interface Type = IBM Port 5B
000123(CR)
Interface Type = IBM 4683 Port 9B
Single cable installations require connection at the POS Terminal (host)
port. The Scale Host port connection is not used for this interface.
Great care should be taken to select the correct interface type, since you
can cause damag
e to the scanner and/or POS terminal by attempting to
change to an incompatible interface. ALWAYS make interface selections
with the host cable DISCONNECTED.

Datalogic Magellan 9800i Specifications

General

Type	Built-in bar code reader
Sensor type	-
Scanner type	1D/2D
Light levels (direct sunlight)	0 - 86080 lx
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Micro QR Code, QR Code, Small Aztec Code
Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power source type	AC
Power consumption (standby)	11 W
Power consumption (typical)	12 W
Standard interfaces	RS-232
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black, Grey
Built-in display	No

Weight and Dimensions

Weight	- g
