Datalogic Magellan 9800i User Manual

Enter/Exit Programming Mode
Product Reference Guide 329
Codabar Start Stop Character Set
This feature specifies the format of transmitted Codabar start/stop characters.
Options are:
•ABCD/TN* E
•ABCD/ABCD
•abcd/tn* e
•abcd/abcd
To set this feature:
1. Scan the ENTER/EXIT Programming Mode bar code.
2. Scan the barcode below or from the following page r
epresenting the desired option. You’ll
need to cover any unused barcodes and facing pages to ensure that the scanner reads only
the barcode you intend to scan.
3. Complete the programming sequence by scanning
the ENTER/EXIT Programming
Mode bar code.
022E00(CR)
Codabar Start Stop Character Set = ABCD/TN* E
022E01(CR)
Codabar Start Stop Character Set = ABCD/ABCD
022E02(CR)
Codabar Start Stop Character Set = abcd/tn* e
022E03(CR)
Codabar Start Stop Character Set = abcd/abcd
DEFAULT

Datalogic Magellan 9800i Specifications

General

Type	Built-in bar code reader
Sensor type	-
Scanner type	1D/2D
Light levels (direct sunlight)	0 - 86080 lx
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Micro QR Code, QR Code, Small Aztec Code
Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power source type	AC
Power consumption (standby)	11 W
Power consumption (typical)	12 W
Standard interfaces	RS-232
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black, Grey
Built-in display	No

Weight and Dimensions

Weight	- g
