Enter/Exit Programming Mode
Product Reference Guide 171
IBM Scale Address
NOTE
This feature applies to IBM Port 17 ONLY.
Specifies IBM scale address for IBM Port 17. The following three addresses are available:
•6A
•6B
•6E
To set the IBM Scale Address:
1. Scan the Enter/Exit Programming Mode bar code.
2. Scan the bar code below that represents the desir
ed scale address designation.
3. Complete the programming sequence by scanning the
Enter/Exit Programming Mode bar
code.
04156A(CR)
IBM Scale Address = 6A
04156B(CR)
IBM Scale Address = 6b
DEFAULT
04156E(CR)
IBM Scale Address = 6E

Datalogic Magellan 9800i Specifications

General

Type	Built-in bar code reader
Sensor type	-
Scanner type	1D/2D
Light levels (direct sunlight)	0 - 86080 lx
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Micro QR Code, QR Code, Small Aztec Code
Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power source type	AC
Power consumption (standby)	11 W
Power consumption (typical)	12 W
Standard interfaces	RS-232
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black, Grey
Built-in display	No

Weight and Dimensions

Weight	- g
