Datalogic Magellan 9800i User Manual

Product Reference Guide 433
AIM Formats
AIM specifies a 3-character string that is attached as a prefix to the label data for
transmission. Because AIM specifies one identifier for UPCA, UPCE and EAN13 labels,
UPCA, UPCE and EAN13 will be received from the handheld and transmitted by the
scanner as EAN13. The ‘]’ character must be the first character received in the label
transmission from the handheld.
The following sections describe the prefix strings and identify what specific label
characteristics can be supported.
UPC-A
• AIM does not specify UPCA as a separate symbology using this transmission format -
labels will be transmitted as EAN13 (refer to section 8.5.4.3).
• Examples: ‘]E00060992011187’ or ‘]E30060992011187’
UPC-E
• AIM does not specify UPCE as a separate symbology using this transmission format -
labels will be transmitted as EAN13 (refer to section 8.5.4.3)..
• Examples: ‘]E00000000998875’ or ‘]E30000000998875’
EAN13
• Check digit must be included in label data and is assumed to be correct.
• Prefix must be ASCII characters ‘]E0’ or ']E3'.
• Total length including prefix must be 16.
• Examples: ‘]E01101234567891’ or ‘]E31101234567891’.
EAN8
• Check digit must be included in label data and is assumed to be correct.
• Prefix must be ASCII characters ‘]E4’.
• Total length including prefix must be 11.
• Example: ‘]E400210126’

Datalogic Magellan 9800i Specifications

General

Type	Built-in bar code reader
Sensor type	-
Scanner type	1D/2D
Light levels (direct sunlight)	0 - 86080 lx
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Micro QR Code, QR Code, Small Aztec Code
Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power source type	AC
Power consumption (standby)	11 W
Power consumption (typical)	12 W
Standard interfaces	RS-232
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black, Grey
Built-in display	No

Weight and Dimensions

Weight	- g
