Datalogic Magellan 9800i User Manual

Enter/Exit Programming Mode
Product Reference Guide 183
RS-232 Hardware Control
Enables/disables use of the RS-232 CTS signal for flow control and/or scan control.
Options are:
• Disable — The scanner transmits to the host regardless of any activity on the CTS line.
• Enable CTS Flow Control — The CTS signal controls transmission of data to the host.
• Enable CTS Scan Control — The CTS line must be activ
e for scanner to read and trans-
mit data. While the CTS line is inactive, scanner remains in a host- disabled state; follow-
ing a successful label transmission, the CTS signal must transition to inactive and then to
activ
e to enable scanning for the next label.
• Enable Magellan SL CTS Scan Control — Follo
ws the same hardware protocol as older
Magellan SL scanners.
To set this feature:
1. Scan the Enter/Exit Programming Mode bar code.
2. Scan bar code below or from the following page for the desired setting. You’ll need to
co
ver any unused bar codes on facing pages to ensure that the scanner reads only the bar
code you intend to scan.
3. Complete the programming sequence by scanning the
Enter/Exit Programming Mode bar
code.
DEFAULT
020F00(CR)
RS-232 Hardware Control = Disable
020F01(CR)
RS-232 Hardware Control = Enable CTS Flow Control
020F02(CR)
RS-232 Parity = Enable CTS Scan Control
020F03(CR)
RS-232 Hardware Control = Enable MGL SL CTS Scan Con-
trol

Datalogic Magellan 9800i Specifications

General

Type	Built-in bar code reader
Sensor type	-
Scanner type	1D/2D
Light levels (direct sunlight)	0 - 86080 lx
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Micro QR Code, QR Code, Small Aztec Code
Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power source type	AC
Power consumption (standby)	11 W
Power consumption (typical)	12 W
Standard interfaces	RS-232
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black, Grey
Built-in display	No

Weight and Dimensions

Weight	- g
