Datalogic Magellan 9800i User Manual

Product Reference Guide 101
Chapter 8
Imaging Features
Top Down Reader (TDR) and Mobile Commerce Imaging
Features
The TDR and its multiple capabilities are optional features with which your scanner may
equipped. The imaging features in this chapter pertain only to the TDR and Mobile
Commerce reader. Figure 55, #1 illustrates the TDR’s top down reading capability and #2
demonstrates the Mobile Commerce reader function.
Figure 55. Top Down Reader and Mobile Commerce Reader
Yo ur
Coupon
Yo ur
Coupon
12
1
Top Down Reader (TDR)
2
Mobile Commerce Reader

Datalogic Magellan 9800i Specifications

General

Type	Built-in bar code reader
Sensor type	-
Scanner type	1D/2D
Light levels (direct sunlight)	0 - 86080 lx
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Micro QR Code, QR Code, Small Aztec Code
Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power source type	AC
Power consumption (standby)	11 W
Power consumption (typical)	12 W
Standard interfaces	RS-232
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black, Grey
Built-in display	No

Weight and Dimensions

Weight	- g
