Datalogic Magellan 9800i User Manual

Product Reference Guide 9
Warm-Up Time
There are two pertinent warm-up times that apply to the scanning-scale:
NOTE
The two warm-up periods can be performed concurrently, thereby reducing the
total required warm-up time to 60 minutes.
Thermal Equilibrium
When the unit is moved from a cooler temperature (such as a storage area) to a warmer
environment (such as a checkstand location), 60 minutes must be allowed to acclimate the unit
to ambient conditions prior to calibration or operation.
Power-up
Once installed and powered up, a warm-up time of 15 minutes must be allowed before
calibrating or performing weighing operations.
Figure 5. Environmental Specifications
Operation
Storage
+40° C +104° F
0° C 32° F
Temperature
+10° to +40° C
50° to +104° F
Dust Resistant Optics Cavity, IP5X
+70° C +158° F
-40° C -40° F
Temperature
-40° to +70° C
-40° to +158° F
Illumination
Artificial Light:
0-200 Foot-candles
(2,152 LUX)
Sunlight:
0-8,000 Foot-candles
(86,114 LUX)
POS Scanner
Humidity
Hot / Wet 40°C / 95% RH
Hot / Dry 40°C / 5% RH
Cold / Dry 10°C / 5% RH
Warm / Wet 25%C / 50% RH
Spill Proof
(Datalogic MS-0006-13-0004)

Datalogic Magellan 9800i Specifications

General

Type	Built-in bar code reader
Sensor type	-
Scanner type	1D/2D
Light levels (direct sunlight)	0 - 86080 lx
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Micro QR Code, QR Code, Small Aztec Code
Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power source type	AC
Power consumption (standby)	11 W
Power consumption (typical)	12 W
Standard interfaces	RS-232
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black, Grey
Built-in display	No

Weight and Dimensions

Weight	- g
