Datalogic Magellan 9800i User Manual

Enter/Exit Programming Mode
Product Reference Guide 283
DataBar Omnidirectional/EAN-128 Emulation
Enables/disables the ability of DataBar Omnidirectional to be transmitted as EAN-128.
1. To set this feature:
2. Scan the ENTER/EXIT Programming Mode bar code.
3. Scan either the enable or disable barcode below. You’ll need to cover any unused barcodes
on
this and the facing page to ensure that the scanner reads only the barcode you intend to
scan.
4. Complete the programming sequence by scanning
the ENTER/EXIT Programming
Mode bar code.
DEFAULT
04D400(CR)
DataBar Omnidirectional/EAN-128 Emulation = Disable
04D401(CR)
DataBar Omnidirectional/EAN-128 Emulation = Enable

Datalogic Magellan 9800i Specifications

General

Type	Built-in bar code reader
Sensor type	-
Scanner type	1D/2D
Light levels (direct sunlight)	0 - 86080 lx
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Micro QR Code, QR Code, Small Aztec Code
Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power source type	AC
Power consumption (standby)	11 W
Power consumption (typical)	12 W
Standard interfaces	RS-232
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black, Grey
Built-in display	No

Weight and Dimensions

Weight	- g
