Datalogic Magellan 9800i User Manual

Product Reference Guide 413
Appendix F
Factory Defaults
The following table provides a listing of the most common factory settings for the interfaces
shown.
NOTE
Some of the individual interfaces listed in the defaults table below appear
in the same column since they share similar feature settings with few (if
any) exceptions.

Keep in mind though, that the actual configuration storage area for each
interface is unique and that updates & changes to factory defaults can be
made at any time without notice.
Table 22. Factory Default Settings
Feature
Default
Master
RS-232
RS-232
Wincor-
Nixdorf
RS-232
Single
Cable
Keyboard
USB COM
/
USB TEC
USB
OEM
IBM
Port 17
Port 9B
Port 5B
Imaging Features
Mobile Commerce
Reader Enable
01 (enable) 01 (enable) 01 (enable) 01 (enable) 01 (enable) 01 (enable) 01 (enable) 01 (enable)
Mobile Commerce
Imagers
00 (Mobile
Commerce
ONLY)
00 (Mobile
Commerce
ONLY)
00 (Mobile
Commerce
ONLY)
00 (Mobile
Commerce
ONLY)
00 (Mobile
Commerce
ONLY)
00 (Mobile
Commerce
ONLY)
00 (Mobile
Commerce
ONLY)
00 (Mobile
Commerce
ONLY)
Mobile Commerce
Button Function
00 (Toggle) 00 (Toggle) 00 (Toggle) 00 (Toggle) 00 (Toggle) 00 (Toggle) 00 (Toggle) 00 (Toggle)
TDR Enable
01 (enable) 01 (enable) 01 (enable) 01 (enable) 01 (enable) 01 (enable) 01 (enable) 01 (enable)
Image Camera
02 (TDR) 02 (TDR) 02 (TDR) 02 (TDR) 02 (TDR) 02 (TDR) 02 (TDR) 02 (TDR)
Image Format
00 (JPG) 00 (JPG) 00 (JPG) 00 (JPG) 00 (JPG) 00 (JPG) 00 (JPG) 00 (JPG)
Image Size
00 (VGA) 00 (VGA) 00 (VGA) 00 (VGA) 00 (VGA) 00 (VGA) 00 (VGA) 00 (VGA)
Image Brightness
Level 0 Level 0 Level 0 Level 0 Level 0 Level 0 Level 0 Level 0
Image Contrast
Level 0 Level 0 Level 0 Level 0 Level 0 Level 0 Level 0 Level 0
General Scanner and Scale Features
1D Double Read
Timeout
28 (400ms) 28 (400ms) 28 (400ms) 28 (400ms) 28 (400ms) 28 (400ms) 28 (400ms) 28 (400ms)
2D Double Read
Timeout
46 (700ms) 46 (700ms) 46 (700ms) 46 (700ms) 46 (700ms) 46 (700ms) 46 (700ms) 46 (700ms)

Datalogic Magellan 9800i Specifications

General

Type	Built-in bar code reader
Sensor type	-
Scanner type	1D/2D
Light levels (direct sunlight)	0 - 86080 lx
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Micro QR Code, QR Code, Small Aztec Code
Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power source type	AC
Power consumption (standby)	11 W
Power consumption (typical)	12 W
Standard interfaces	RS-232
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black, Grey
Built-in display	No

Weight and Dimensions

Weight	- g
