Datalogic Magellan 9800i User Manual

Product Reference Guide 33
Figure 21
Model 9805
& Model 9806
Cutout
Model 9805
& Model 9806
Supports
51.12cm
(20.125")
1.905cm
(0.75")
47.308cm
(18.625")
Rail
Rail
(Center Line)
29.53cm
(11.625")
1.905cm
(0.75")
Max. Radius = 0.635cm
(0.25") 4x
51.2 ±0.15 cm
(20.125" ±0.06")
47.3 ±0.15 cm
(18.625" ± .060")
0.952 ±0.07 cm
(0.375" ± .030")
0.952 ±0.07 cm
(0.375" ± .030")
If leveling feet are needed
for models 9805 and 9806,
use the placement shown here,
represented with plus signs (+).
7.77 ±0.15 cm
(3.06" ± .006")
7.77 ±0.15 cm
(3.06" ± .006")
1.9 cm
(0.75")
3.8 cm
(1.5")
1.9 ±0.15 cm
(0.75"± .060")
1.9 ±0.15 cm
(0.75"± .060")
10.2 cm
(4.0")
0.95 ± 0.08 cm (0.375" ± 0.03")
Liquid
Drainage
Liquid
Drainage
. Models 9805 and 9806 Long Scanner or Scanning-Scale Reference Dimensions
Figure 22. Models 9805 and 9806 Long Scanner
or Scanning-Scale Reference Dimensions
Model 9805
& Model 9806
Reference
Dimensions
8.7 kg
(19.25 lb)
Scanner/Scale
Weight
6.9 kg
(15.25 lb)
Scanner
Weight (w/o scale)
43.7cm (17.20”)
50.69cm (19.96”)
23.74cm (9.35”)
34.9cm (13.74”)
34.9cm (13.74”)
9.46cm
(3.72”)
6.9cm
(2.72”)
10.06cm
(3.96”)
10.36cm
(4.08”)
9.1cm
(3.58”)
29.21cm
(11.5”)
9.1cm
(3.58”)
Window
TDR adds 0.3 kg (0.75 lb)

Datalogic Magellan 9800i Specifications

General

Type	Built-in bar code reader
Sensor type	-
Scanner type	1D/2D
Light levels (direct sunlight)	0 - 86080 lx
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Micro QR Code, QR Code, Small Aztec Code
Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power source type	AC
Power consumption (standby)	11 W
Power consumption (typical)	12 W
Standard interfaces	RS-232
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black, Grey
Built-in display	No

Weight and Dimensions

Weight	- g
