UNLOCK_ONCE This bit is a sticking indication of FMPLL loss of lock condition. UNLOCK_ONCE is set when the
FMPLL loses lock. Whenever the FMPLL reacquires lock, UNLOCK_ONCE remains set. Only a
power-on reset clears this bit.
I_LOCK This bit is set by hardware whenever there is a lock/unlock event.
S_LOCK This bit is an indication of whether the FMPLL has acquired lock.
0: FMPLL unlocked
1: FMPLL locked
Note:
PLL_FAIL_MASK This bit is used to mask the pll_fail output.
0 pll_fail not masked.
1 pll_fail masked.
PLL_FAIL_FLAG This bit is asynchronously set by hardware whenever a loss of lock event occurs while FMPLL
is switched on. It is cleared by software writing ‘1’.
Table 6-10. Input divide ratios
IDF[3:0] Input divide ratios
0000 Divide by 1
0001 Divide by 2
0010 Divide by 3
0011 Divide by 4
0100 Divide by 5
0101 Divide by 6
0110 Divide by 7
0111 Divide by 8
1000 Divide by 9
1001 Divide by 10
1010 Divide by 11
1011 Divide by 12
1100 Divide by 13
1101 Divide by 14
1110 Divide by 15
1111 Clock Inhibit
