25.4.4 Threshold registers
25.4.4.1 Introduction
These four registers are used to store the user programmable lower and upper thresholds’ values.
25.4.4.2 Threshold Control Register (TRCx, x = [0..3])
Address: Base + 0x0050 (TRC0)
Base + 0x0054 (TRC1)
Base + 0x0058 (TRC2)
Base + 0x005C (TRC3) Access: User read/write
0123456789101112131415
R00000000 00000 000
W
Reset0000000000000000
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R
THR
EN
0000000 0 THRCH
W
Reset0000000000000000
Figure 25-20. Threshold Control Register (TRCx, x = [0..3])
Table 25-15. TRCx field descriptions
Field Description
THREN Threshold enable
When set, this bit enables the threshold detection feature for the selected channel.
THRCH Choose the channel for threshold comparison.
