Freescale Semiconductor MPC5604B - Register Map

MPC5604B/C Microcontroller Reference Manual, Rev. 8
848 Freescale Semiconductor
Reserved — — (Base + 0x000C) –
(Base + 0x003F)
Power Domain Status Register PSTAT 32-bit Base + 0x0040
Reserved — — (Base + 0x0044) –
(Base + 0x007C)
Voltage Regulator Control Register VCTL 32-bit Base + 0x0080
Reserved — — (Base + 0x0084) –
(Base + 0x3FFF)
Real Time Counter (RTC/API) 0xC3FE_C000
RTC Supervisor Control Register RTCSUPV 32-bit Base + 0x0000
RTC Control Register RTCC 32-bit Base + 0x0004
RTC Status Register RTCS 32-bit Base + 0x0008
RTC Counter Register RTCCNT 32-bit Base + 0x000C
Reserved — — (Base + 0x0010) –
(Base + 0x3FFF)
Periodic Interrupt Timer (PIT) 0xC3FF_0000
PIT Module Control Register PITMCR 32-bit Base + 0x0000
Reserved — — Base + (0x0004 –
0x00FC)
Timer Load Value Register LDVAL0 32-bit Base + 0x0100
Current Timer Value Register 0 CVAL0 32-bit Base + 0x0104
Timer Control Register 0 TCTRL0 32-bit Base + 0x0108
Timer Flag Register 0 TFLG0 32-bit Base + 0x010C
Timer Load Value Register 1 LDVAL1 32-bit Base + 0x0110
Current Timer Value Register 1 CVAL1 32-bit Base + 0x0114
Timer Control Register 1 TCTRL1 32-bit Base + 0x0118
Timer Flag Register 1 TFLG1 32-bit Base + 0x011C
Timer Load Value Register 2 LDVAL2 32-bit Base + 0x0120
Current Timer Value Register 2 CVAL2 32-bit Base + 0x0124
Timer Control Register 2 TCTRL2 32-bit Base + 0x0128
Timer Flag Register 2 TFLG2 32-bit Base + 0x012C
Timer Load Value Register 3 LDVAL3 32-bit Base + 0x0130
Current Timer Value Register 3 CVAL3 32-bit Base + 0x0134
Timer Control Register 3 TCTRL3 32-bit Base + 0x0138
Table A-2. Detailed register map (continued)
Register description Register name
Used
size
Address
