MPC5604B/C Microcontroller Reference Manual, Rev. 8

Freescale Semiconductor 829

GPIO Pad Data Output Register GPDO88_91 32-bit Base + 0x0658

GPIO Pad Data Output Register GPDO92_95 32-bit Base + 0x065C

GPIO Pad Data Output Register GPDO96_99 32-bit Base + 0x0660

GPIO Pad Data Output Register GPDO100_103 32-bit Base + 0x0664

GPIO Pad Data Output Register GPDO104_107 32-bit Base + 0x0668

GPIO Pad Data Output Register GPDO108_111 32-bit Base + 0x066C

GPIO Pad Data Output Register GPDO112_115 32-bit Base + 0x0670

GPIO Pad Data Output Register GPDO116_119 32-bit Base + 0x0674

GPIO Pad Data Output Register GPDO120_123 32-bit Base + 0x0678

Reserved — — Base + (0x067C –

0x07FF)

GPIO Pad Data Input Register GPDI0_3 32-bit Base + 0x0800

GPIO Pad Data Input Register GPDI4_7 32-bit Base + 0x0804

GPIO Pad Data Input Register GPDI8_11 32-bit Base + 0x0808

GPIO Pad Data Input Register GPDI12_15 32-bit Base + 0x080C

GPIO Pad Data Input Register GPDI16_19 32-bit Base + 0x0810

GPIO Pad Data Input Register GPDI20_23 32-bit Base + 0x0814

GPIO Pad Data Input Register GPDI24_27 32-bit Base + 0x0818

GPIO Pad Data Input Register GPDI28_31 32-bit Base + 0x081C

GPIO Pad Data Input Register GPDI32_35 32-bit Base + 0x0820

GPIO Pad Data Input Register GPDI36_39 32-bit Base + 0x0824

GPIO Pad Data Input Register GPDI40_43 32-bit Base + 0x0828

GPIO Pad Data Input Register GPDI44_47 32-bit Base + 0x082C

GPIO Pad Data Input Register GPDI48_51 32-bit Base + 0x0830

GPIO Pad Data Input Register GPDI52_55 32-bit Base + 0x0834

GPIO Pad Data Input Register GPDI56_59 32-bit Base + 0x0838

GPIO Pad Data Input Register GPDI60_63 32-bit Base + 0x083C

GPIO Pad Data Input Register GPDI64_67 32-bit Base + 0x0840

GPIO Pad Data Input Register GPDI68_71 32-bit Base + 0x0844

GPIO Pad Data Input Register GPDI72_75 32-bit Base + 0x0848

GPIO Pad Data Input Register GPDI76_79 32-bit Base + 0x084C

GPIO Pad Data Input Register GPDI80_83 32-bit Base + 0x0850

Table A-2. Detailed register map (continued)

Used

size

Address
