Freescale Semiconductor MPC5604B - Register Map

MPC5604B/C Microcontroller Reference Manual, Rev. 8
Freescale Semiconductor 843
eMIOS_1 UC23 B Register eMIOS1_UC23_B 32-bit Base + 0x0304
eMIOS_1 UC23 CNT eMIOS1_UC23_CNT 32-bit Base + 0x0308
eMIOS_1 UC23 Control Register eMIOS1_UC23_SC 32-bit Base + 0x030C
eMIOS_1 UC23 Status Register eMIOS1_UC23_SS 32-bit Base + 0x0310
System Status and Configuration Module (SSCM) 0xC3FD_8000
System Status Register STATUS 16-bit Base + 0x0000
System Memory Configuration Register MEMCONFIG 16-bit Base + 0x0002
Reserved — — Base + (0x0004 –
0x0005)
Error Configuration ERROR 16-bit Base + 0x0006
Reserved — — Base + (0x0008 –
0x000B)
Password Comparison Register High Word PWCMPH 32-bit Base + 0x000C
Password Comparison Register Low Word PWCMPL 32-bit Base + 0x0010
Reserved — — Base + (0x0014 –
0x3FFF)
Mode Entry Module (MC_ME) 0xC3FD_C000
Global Status ME_GS 32-bit Base + 0x0000
Mode Control ME_MCTL 32-bit Base + 0x0004
Mode Enable ME_ME 32-bit Base + 0x0008
Interrupt Status ME_IS 32-bit Base + 0x000C
Interrupt Mask ME_IM 32-bit Base + 0x0010
Invalid Mode Transition status ME_IMTS 32-bit Base + 0x0014
Debug Mode Transition status ME_DMTS 32-bit Base + 0x0018
RESET Mode Configuration ME_RESET_MC 32-bit Base + 0x0020
TEST Mode Configuration ME_TEST_MC 32-bit Base + 0x0024
SAFE Mode Configuration ME_SAFE_MC 32-bit Base + 0x0028
DRUN Mode Configuration ME_DRUN_MC 32-bit Base + 0x002C
RUN0 Mode Configuration ME_RUN0_MC 32-bit Base + 0x0030
RUN1 Mode Configuration ME_RUN1_MC 32-bit Base + 0x0034
RUN2 Mode Configuration ME_RUN2_MC 32-bit Base + 0x0038
RUN3 Mode Configuration ME_RUN3_MC 32-bit Base + 0x003C
HALT Mode Configuration ME_HALT_MC 32-bit Base + 0x0040
Table A-2. Detailed register map (continued)
Register description Register name
Used
size
Address
